Optimal flow of air
The option of 2,3,4 blow directions
There are three blow solutions to select from between two directions, three directions, and four directions to accommodate a wide range of installations. For example: When you choose four directions in the middle of the room and three directions for installation in the corner of the room.
Customize the path of the air blow
The air blow may be adjusted or modified with a remote controller to directly or indirectly alter the direction of the wind.
The multi-directional air conditioning system
The flexible orientation of the blade and the orientation of the airflow provide the ideal combination for the best airflow setting to ensure a uniform temperature distribution in the air-conditioned room.
The effect is that the space is air-conditioned uniformly and conveniently for the inhabitants.
Fitting with high ceilings and low ceilings
The indoor unit is equipping with high and low ceiling operating modes that can adjust the airflow to accommodate the height of the room. Choosing the optimum airflow helps to create a cooling atmosphere for the whole room.
Automatically change the speed of the wind
The mode automatically controls the wind level to ensure comfortable space conditions are maintaining at all times. This setting makes it possible to adjust the wind speed automatically according to the room temperature conditions.
3D i-see Sensor (optional)
Detect people in a room with high precision
A total of 8 sensors spin at 360 ° every 3 minutes. In addition to measuring body temperature, the device can calculate precisely the number of people in the room and their locations using algorithms.
Detection of the number of people in the room
Energy-saving mode based on the number of people: 3D I sensor senses the number of people in the room. Calculate the number of people in the room to adapt the operation to the actual time. As the number of people reduces by 30%, the room temperature increases by 1 ° C (as cooled) or low by 1 ° C (when heated) to save electricity. The temperature is regulated based on the number of people present in the room.
Energy-saving mode when there are no people: when the 3D I sensor senses that there are no people in the room, the device changes to energy-saving mode. Whether the space is unoccupied for around 60 minutes, the space temperature rises by 2 ° C (when cooled) or falls by 2 ° C (when heated) to conserve energy. It helps the reduction of energy losses during cooling and heating.
Auto-off mode while no users are present: while the space is unoccupied for a predetermined period, the air conditioner shuts off automatically, saving more energy. The time before deactivation can set from 80 to 180 minutes, with a time of 10 minutes. (* Auto-switch mode when no user is present when multiple indoor units are running with the MA controller.)
Detection of the location of people in the room
Setting Direct / Indirect Air Path *
Some people don't want the wind blowing directly on them, and others prefer to cool from head to toe. The amount of likes and dislikes varies. With the 3D I sensor, you can pick the correct direct/indirect wind direction for each person by adjusting the blades of the island in the indoor unit. (PAR-32MAA or PAR-SL100A-E is needed to be installed)
Seasonal cold winds *
When cooling: conserve energy when keeping temperatures comfortable by alternating between ventilation and cooling automatically. When the fixed temperature is achieving, the air conditioner changes to swing mode to ensure that the room temperature is a control efficiently. This intelligent feature helps to keep the user calm and relaxed. (PAR-32MAA is a requirement to install.)
Heating: The air conditioner automatically changes between air circulation and heating. The heat radiated near the roof is reused by the circulation of the wind. When the set temperature is achieving, the air conditioner changes from heating to air circulation and blasts the air horizontally. It helps to drives the intense stream of hot air near the ceiling down to the customer, delivering smart heating. (PAR-32MAA is a requirement to install)
Easy to install
Temporary hanger
The structure of the mask sheet has been redesigned and is fitting with a temporary hook. It helps to increased work productivity during installation.
Electrical box
The redesigned electrical box arrangement makes it simpler to connect electrical wires to the indoor unit.
No need to remove any screws
You can assemble without cutting the screws at the corner of the panel and the control box, and loosen them. It helps to reduce the chance of failure of screws.
Increase space for copper pipe fitting
The upper and lower positions of the liquid and steam tubes have reversed allow the connection of the steam tube, which requires more force, completed in advance. Furthermore, through the pipes repositioning, the pipe wrench angle is increasing from 50o to 70o, which improves the piping connection and allows the job to complete smoothly.
Easy to clean (optional)
With the automatic lifting and lowering of the mask, cleaning the filter screen is easy, even for high ceilings.
Specifications
