External Static Pressure(E.S.P) control
You can set External Static Pressure (E.S.P.) bymethod of manual setting on remote control.Indoor unit will control fan-speed to keep rated airflow volume at each fan speed setting. You can set required E.S.P. by wired remote control that calculated with the set air flow rate and pressure loss of the duct connected.
Thin design
Reduction of sound pressure level
Transparent inspection window
Dirt condition of the bottom of a drain pan can be checked through this transparent inspection window without removing drain pan.
Remote control (option)
Specifications
1. The data are measured under the following conditions(ISO-T1). Cooling: Indoor temp. of 27ºCDB, 19ºCWB, and outdoor temp. of 35ºCDB. Heating: Indoor temp. of 20ºCDB, and outdoor temp. of 7ºCDB, 6ºCWB. External static pressure of indoor unit is 60Pa.
2. Sound pressure level indicates the value in an anechoic chamber. During operation these values are somewhat higher due to ambient conditions.
*Powerful-Hi can be selected. Sound pressure level: FDU45/56 37dB(A), FDU71/90 38dB(A), FDU112 44dB(A), FDU140 45dB(A),FDU160 47dB(A). Air flow: FDU45/56 13m3/min, FDU71/90 24m3/min, FDU112 36m3/min, FDU140 39m3/min, FDU160 48m3/min.
