Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)
Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)

- Chỉ số tiết kiệm điện cao hơn dòng tiêu chuẩn

- Độ ồn thấp hơn dòng tiêu chuẩn

- Khối lượng dàn nóng nặng hơn, dàn đồng dày hơn.

Daikin Air Conditioner Inverter FTKV71NVMV (3.0Hp)

34,050,000
Phí vật tư có thể phát sinh: 965,000đ. Xem chi tiết vật tư.

Email: kinhdoanh@sieuthimaylanh.com
(Open 08. am-17.pm everyday)
Warranty
02 years for components
05 years for compressor
Capacity
Air Conditioner 3.0 HP
Type
Inverter Air Conditioner
Refrigerant
Gas R32
Specifications
Made in:Japanese brand, Made in Thailand
Refrigerant:R32
Type:Inverter AC - Cooling Only
Cooling Capacity:3.0 Hp - 24.200 Btu/h
Use For Room:Room Area 40 - 45 m² or Volume 92 - 102 m³ ( Suitable for living room, office )
Power Input (Ph/V/Hz):1 Phase, 220 - 240 V, 50Hz
Power consumption (kW):1,58 Kw
Refrigerant/ Liquid Pipe Diameter (mm):6.35 / 15.9
Maximum Pipe Length:30 (m)
Maximum Elevation Length:20 (m)
Cooling Seasonal Performance Factor (CSPF):5.19
Energy Efficiency Level:5 star
Indoor Unit
Indoor Unit Model:FTKV71NVMV
Indoor Unit Dimensions (mm):340 x 1.050 x 248 (mm)
Indoor Unit Net Weight (Kg):14 (kg)
Outdoor Unit
Outdoor Unit Model:RKV71NVMV
Outdoor Unit Dimensions (mm):770 x 900 x 320 (mm)
Outdoor Unit Net Weight (Kg):60 (kg)
Description

It's Time for DC Inverter. Inverter air conditioners are well known for their precise control.

In fact, their outstanding efficiency can cut energy bills compared to non-inverter models. This precision also means greater comfort, plus full power at the touch of a button.

  • Improved performance over non-inverter models
  • Optimal control with Intelligent Eye and Econo Mode
  • Advanced comfort features including 3-D Airflow
  • Greater convenience with weekly scheduling
  • Titanium Apatite Photocatalytic Air-Purifying Filter

Next-Generation Refrigerant R-32

To cope with climate change, Daikin has now adopted
R-32, next-generation refrigerant which does not deplete the ozone layer and lower global warming.

pic_r-32_m

* Source: Values for 100 year global warming potential (GWP) from IPCC Fourth Assessment Report. Comparative 100 year GWP: HFC410A, 2,090; HFC32, 675.

Inverter Technology

Energy Saving

After the indoor temperature approaches the set temperature, inverter control adjusts to low capacity operation to maintain this temperature, making inverter models more energy saving than non-inverter models.

Powerful

Inverter air conditioners operate at maximum capacity as soon as they start up. This burst of increased power allows them to reach the set temperature more quickly.

Comfortable

Inverter air conditioners adjust capacity according to changes in the air conditioning load and the difference between the indoor temperature and set temperature is small, giving higher comfort levels than with non-inverter air conditioners.

pic_comfortable_m

Titanium Apatite Photocatalytic Air-Purifying Filter

While the filter’s micron-level fibres trap dust, titanium apatite effectively adsorbs odours and allergens, as well as deodorises odours. This filter delivers consistent performance for approximately three years if it is washed with water once every six months.

pic-clean-air

Intelligent Eye

Detect human movement in a room by using infrared sensor to prevent energy wastage.

pic_intelligent_eye_m

Smart Control by Smartphone
The Daikin mobile controller application lets you manage Daikin inverter air conditioners from anywhere, helping to maintain a comfortable home environment while saving energy.
This convenient app gives you full control of core functions such as start/stop, operation mode and set temperature as well as advanced features like ưeekly scheduling. The app also lets you monitor your system to ensure it is performing as desired.
Setup is extremely easy. After downloading the software, you only need to connect to a private wireless network inside your home or mobile network outside.
Out of Home Operation
The Daikin mobile controller application takes care of those nagging worries about whether you turned of the air conditioner and ensures a comfortable air conditioned environment is waiting when you return home. Even outside your home, you can easily monitor and adjust points such as the operating status and room temperature or start and stop all units.

Daikin_FTKC25RVMV_1

In Home Operation
At home, the Daikin mobile controller application turns your smartphone into a centralised remote controller? It only takes a few easy taps to check and adjust the temperature in a child's room on the second floor from the living room. You can also start and stop the air conditioner in the living room from your bedroom.

Daikin_FTKC25RVMV_3

Anticorrosion Treatment of Outdoor Heat Exchanger Fins

The surface of heat exchanger fins is covered with a thin acrylic resin layer to enhance the fins' resistance to acid rain and salt corrosion. A hydrophilic film layer also prevents rust caused by the run off of water droplets.

pic_anticorrosion_treatment_m

Indoor Unit Quiet Operation

The whole series give you a choice of 5-step, Quiet or Automatic settings for the fan speed. The Quiet setting selects Indoors Unit Quiet Operation, which decreases the sound pressure level 3 to 6 dB (A) below the Low setting and help you to sleep comfortably at night..

pic_indoor_unit_quiet_operation

Outdoor Unit Quiet Operation

This function decreases the sound pressure level by 3 to 7 24 Hour On/Off Timer
dB (A) below the rated operation. It provides a sound pressure
level of 43 dB (A)1 for the RKV25, RXV25, RKC50/60 and
RHM50/60. Capacity may decrease when Outdoor Unit Quiet
Operation is selected.

Daikin_FTKV25NVMV_5

Daikin_FTKV25NVMV_6

This function is not available for the RXM20/25/35.

Weekly Timer

Up to four actions can be programmed for each day of the week. Possible to schedule for on, off times and set temperature.
The Weekly Timer synchronizes the air conditioner with your family's schedule, greatly improving comfort in your home.
This function is available for models FTKV50/60.

Daikin_FTKV25NVMV_1

3-D Airflow

3-D airflow combines vertical and horizontal auto-swing to circulate air to every part of a room for uniform cooling of even large spaces.
This function is available for models FTKV50/60

pic_3-d_airflow_m

Daikin_FTKV25NVMV_9

Specifications

Daikin_FTKV25NVMV_7

Note: The above values are based on operation with a 220 V, 50 Hz power supply.
Measurement conditions:

1. Cooling capacity is based on: indoor temp. 27°CDB, 19°CWB; outdoor temp. 35°CDB; piping length 7.5 m.
2. Sound pressure levels are based on the temperature conditions 1 above. These are anechoic conversion values. These values are normally somewhat higher during actual operation as a result of ambient conditions.
